CCC016-01 (C2C48E30)
USB2.0 240W C to C EPR Cable
3M
DESCRIPTIONS
USB is one of Elka’s main product lines. Elka has a full range of certified USB cables, covering USB-C™, Standard-A, Standard-B and Micro-B. Elka’s USB-C to C cable can support data transfer rate up to 10Gbps and a level of power up to 5A with 20V voltage. This cable is for the purpose of connecting your USB-C devices for data transfer, fast charging, or video display.
FEATURES
．Certified by USB-IF
．USB Power Delivery, PD3.1 240W(48V/5A) charging
．EPR voltage is limited to a maximum of 48V
．This cable support data speed of USB 2.0 up to 480Mbps
．The connected device must be compatible with USB Power Delivery EPR and USB Power Delivery
．USB Power Delivery, PD3.1 240W(48V/5A) charging
．EPR voltage is limited to a maximum of 48V
．This cable support data speed of USB 2.0 up to 480Mbps
．The connected device must be compatible with USB Power Delivery EPR and USB Power Delivery
APPLICATIONS
．Notebook PC
．Power
．USB Hard Disk Drive
．Power
．USB Hard Disk Drive
| ITEM | CONTENT |
| USB Spec | USB 2.0 |
|---|---|
| Maximum Data Transfer Rate | 480Mbps |
| Length | 3M |
| OD | 5.2mm |
| Type | EPR USB-C Cable |
| Jacket | PVC |
| Plugs1 | USB-C Male, Nickel-Plated |
| Plugs2 | USB-C Male, Nickel-Plated |
| Housings1 | PVC overmold |
| Housings2 | PVC overmold |
| Power Source | Bus Power |
| Output Current and Voltage | 5A/48V/240W |
